Our Pds 3000
This PDS rig is engineered to deliver reliable performance, precision, and efficiency in foundation work. Review the technical specifications for an overview of the machine’s key features and capabilities.
Specifications
PDS 3000:
Standard leader length = 50 m
Max. leader length = 60 m
Standard boom length = 62 m
Max. weight hammer + pile = 100 ton
Emission regulation = Stage V
Engine = C13
Max. lifting capacity at 4.2 m = 300 (5m)
Capacity main winch = 20 ton
Capacity of aux. winch = 15 ton
Engine output = 350/475 kW/HP
Transport width = 4820 mm
Transport length = 12500 mm
Transort height = 3700 mm
Transport weight = 98 ton
